Gyqfxtby Optical Cable

Product Description

Central raj hom non-hlau reinforced xob laim tiv thaiv 2-12 cores optical cable GYQFXTBY

Nqe lus piav qhia:
Cov fibers, 250µm, yog positioned nyob rau hauv ib tug xoob raj ua los ntawm ib tug siab modulus yas. Cov hlab yog ntim nrog cov dej-resistant filling compound. Ob qho tib si uas tsis yog-hlau reinforcements yog muab tso rau ntawm ob sab thiab polyethylene sheath yog extruded los tsim ib lub cable.

Yam ntxwv:

Tshwj xeeb raj filling compound ua kom muaj kev tiv thaiv tseem ceeb ntawm fiber ntau

Full-section dej thaiv cov qauv, ob chav coated APL noo noo barrier los xyuas kom meej lub cable watertight:

Ob qho tib si puag ncig steel hlau yog resistant rau nro thiab sab siab

Lub raj xoob yog nyob rau hauv lub cev qhov chaw ntawm lub optical cable uas yooj yim rau kev tsim kho thiab kev ua haujlwm

PE sheath tiv thaiv cable los ntawm ultraviolet hluav taws xob

Cov kab hluav taws xob kho qhov muag muaj qhov me me sab nraud, lub teeb yuag, kev ua haujlwm zoo heev

Pav ca profile txo qhov chaw hauv cov kav dej

Cov khoom siv kev pab cuam lub neej yog ntau tshaj 25 xyoo;

Ua haujlwm kub: -40 ~ ntxiv rau 70ºC

Daim ntawv thov:

Kev sib txuas lus ntev thiab kev sib txuas lus hauv chaw ua haujlwm

Lub cev, Aerial

Technical Parameters


Hom kab	Fiber suav	Cov raj	Xa mus rau sab nraud txoj kab uas hla(mm)	Cable Nyhav kg/km (Ref)	Tensile Strength Ntev/Short Term(N)	Crush Resistance Ntev / luv luv (N / 100mm)	Khoov Radius Static / Dynamic (mm)
GYQFXTBY-2~12B1.3	2~12	1	4.1×8.1	37	Ntau dua lossis sib npaug rau 600 / Ntau tshaj los yog sib npaug rau 1500	Ntau dua lossis sib npaug rau 1000 / Ntau dua lossis sib npaug li 2000	25D/50D
GYQFXTBY-24B1.3	14~24	1	5.0×9.0	50

Lus Cim: Fiber: G652D los yog raws li tus neeg yuav tsum tau muaj.
